TPLH-2R7/6.0WR8X26
ActiveTecate Group
CAP 6F 2.7V T/H
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TPLH-2R7/6.0WR8X26
ActiveTecate Group
CAP 6F 2.7V T/H
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TPLH-2R7/6.0WR8X26 |
|---|---|
| Capacitance | 6 F |
| ESR (Equivalent Series Resistance) | 85 mOhm |
| Height - Seated (Max) [Max] [z] | 1.102 in |
| Height - Seated (Max) [Max] [z] | 28 mm |
| Lead Spacing | 3.5 mm |
| Lead Spacing | 0.138 in |
| Lifetime @ Temp. | 1500 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Radial, Can |
| Size / Dimension [diameter] | 0.315 " |
| Size / Dimension [diameter] | 8 mm |
| Termination | PC Pins |
| Voltage - Rated | 2.7 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 500 | $ 0.82 | |
Description
General part information
TPLH-2R7/6.0WR8X26
6 F (EDLC) Supercapacitor 2.7 V Radial, Can 85mOhm @ 1kHz 1500 Hrs @ 85°C
Documents
Technical documentation and resources
