2SK1482-T-AZ

Active

Conec

30V 1.5A 400MΩ@10V,0.5A 750W 1.3V 1 N-CHANNEL TO-92 MOSFETS ROHS

Search across all available documentation for this part.

Active

Conec

30V 1.5A 400MΩ@10V,0.5A 750W 1.3V 1 N-CHANNEL TO-92 MOSFETS ROHS

Technical Specifications

Parameters and characteristics for this part

Specification	2SK1482-T-AZ

Current - Continuous Drain (Id) @ 25°C	1.5 A
Drain to Source Voltage (Vdss)	30 V
Drive Voltage (Max Rds On, Min Rds On) [Max]	4 V
Drive Voltage (Max Rds On, Min Rds On) [Min]	10 V
FET Type	N-Channel
Input Capacitance (Ciss) (Max) @ Vds	230 pF
Mounting Type	Through Hole
Operating Temperature	150 °C
Package / Case	TO-226-3, TO-92-3
Power Dissipation (Max)	750 W
Rds On (Max) @ Id, Vgs	400 mOhm
Supplier Device Package	TO-92
Technology	MOSFET (Metal Oxide)
Vgs (Max)	20 V
Vgs(th) (Max) @ Id [Max]	2.5 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

N-Channel 30 V 1.5A (Ta) 750W (Ta) Through Hole TO-92

Technical documentation and resources

No documents available
