BPDN00040430220T00
ActivePulse Electronics
INDUCTOR POWER
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | BPDN00040430220T00 |
|---|---|
| Current - Saturation (Isat) | 760 mA |
| Current Rating (Amps) | 0.74 A |
| DC Resistance (DCR) | 335 mOhm |
| Height - Seated (Max) | 3 mm |
| Height - Seated (Max) [Max] | 0.118 in |
| Inductance | 22 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Tolerance | 30 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 6000 | $ 0.37 | |
Description
General part information
BPDN00040430220T00
22 µH Shielded Inductor 740 mA 335mOhm Max Nonstandard
