R050S
ActiveChip Shine / CSRF
ICT TEST PROBE RECEPTACLE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
R050S
ActiveChip Shine / CSRF
ICT TEST PROBE RECEPTACLE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | R050S |
|---|---|
| Current Rating (Amps) | 3 A |
| Length - Overall [x] | 40.64 mm |
| Length - Overall [x] | 1.6 in |
| Length - Tip | 0.22 in |
| Length - Tip | 5.59 mm |
| Material - Body | Phosphor Copper, Gold Plated |
| Tip Type | Spring Tip - Solder Connection |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 100 | $ 1.50 | |
| 500 | $ 1.48 | |||
| 1000 | $ 1.45 | |||
| 2500 | $ 1.40 | |||
| 5000 | $ 1.30 | |||
Description
General part information
R050S
3 A Spring Tip - Solder Connection
