AB-D20100-V24-Q
ActiveAmerican Bright Optoelectronics Corporation
100-240VAC INPUT, 24VDC OUTPUT,
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AB-D20100-V24-Q
ActiveAmerican Bright Optoelectronics Corporation
100-240VAC INPUT, 24VDC OUTPUT,
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AB-D20100-V24-Q |
|---|---|
| Approval Agency | cULus, TUV, cURus, CE, UKCA |
| Current - Output (Max) [Max] | 4.16 A |
| Efficiency | 89 % |
| Features | OTP, SCP, OVP, OCP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 45 °C |
| Operating Temperature [Min] | -20 C |
| Power (Watts) | 100 W |
| Ratings | IP20 |
| Size / Dimension [x] | 320.6 mm |
| Size / Dimension [x] | 12.62 in |
| Size / Dimension [y] | 30 mm |
| Size / Dimension [y] | 1.18 in |
| Size / Dimension [z] | 0.72 " |
| Size / Dimension [z] | 18.2 mm |
| Termination Style | Terminal Block |
| Topology | AC DC Converter |
| Type | Constant Voltage |
| Voltage - Input (Max) [Max] | 240 VAC |
| Voltage - Input (Min) [Min] | 100 VAC |
| Voltage - Output | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 43.18 | |
| 5 | $ 40.90 | |||
| 10 | $ 38.63 | |||
| 25 | $ 36.93 | |||
| 50 | $ 35.22 | |||
| 100 | $ 34.09 | |||
| 250 | $ 31.25 | |||
Description
General part information
AB-D20100-V24-Q
4.16A 24V Constant Voltage LED Driver AC DC Converter Topology 1 Output
