AK3000/2-5.0-PEBBLEGREY
ActivePTR HARTMANN
TERM BLK 2POS 5.0MM 0.197" PCB
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AK3000/2-5.0-PEBBLEGREY
ActivePTR HARTMANN
TERM BLK 2POS 5.0MM 0.197" PCB
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AK3000/2-5.0-PEBBLEGREY |
|---|---|
| Clamp Material - Plating | Stainless, Steel |
| Color | Gray |
| Current | 15 A |
| Mating Orientation | 135 ° |
| Mating Orientation | 45 ° |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 5 mm |
| Pitch [x] | 0.197 in |
| Positions Per Level | 2 |
| Voltage | 300 V |
| Wire Gauge [Max] | 28 AWG |
| Wire Gauge [Min] | 14 AWG |
| Wire Termination | Screwless - Spring Cage, Tension Clamp |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 0.96 | |
| 10 | $ 0.67 | |||
| 25 | $ 0.63 | |||
| 50 | $ 0.57 | |||
| 200 | $ 0.57 | |||
| 400 | $ 0.48 | |||
| 600 | $ 0.45 | |||
| 1000 | $ 0.40 | |||
| 5000 | $ 0.33 | |||
Description
General part information
AK3000/2-5.0-PEBBLEGREY
2 Position Wire to Board Terminal Block 45° (135°) Angle with Board 0.197" (5.00mm) Through Hole
