16EB90
ActiveAcopian Power Supplies
AC/DC CONVERTER
Deep-Dive with AI
Search across all available documentation for this part.
16EB90
ActiveAcopian Power Supplies
AC/DC CONVERTER
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 16EB90 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus |
| Current - Output 1 | 900 mA |
| Features | Adjustable Output |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -20 C |
| Size / Dimension [x] | 89.7 mm |
| Size / Dimension [x] | 3.53 " |
| Size / Dimension [y] | 2.53 " |
| Size / Dimension [y] | 64.3 mm |
| Size / Dimension [z] | 61.7 mm |
| Size / Dimension [z] | 2.43 " |
| Type | Enclosed |
| Voltage - Input [Max] | 125 VAC |
| Voltage - Input [Min] | 105 VAC |
| Voltage - Output 1 | 16 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 293.48 | |
| 5 | $ 288.23 | |||
| 10 | $ 282.98 | |||
| 25 | $ 277.73 | |||
Description
General part information
16EB90
Enclosed AC DC Converters 1 Output 16V 105 ~ 125 VAC Input
Documents
Technical documentation and resources
