LFXTAL082123
ActiveIQD FREQUENCY PRODUCTS
CRYSTAL, 24MHZ, 8PF, 2MM X 1.6MM ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
LFXTAL082123
ActiveIQD FREQUENCY PRODUCTS
CRYSTAL, 24MHZ, 8PF, 2MM X 1.6MM ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | LFXTAL082123 |
|---|---|
| Frequency | 24 MHz |
| Frequency Stability | 15 ppm |
| Frequency Tolerance | 10 ppm |
| Height - Seated (Max) [Max] [z] | 0.5 mm |
| Height - Seated (Max) [Max] [z] | 0.02 " |
| Load Capacitance | 8 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 2 mm |
| Size / Dimension [x] | 0.079 in |
| Size / Dimension [y] | 0.063 in |
| Size / Dimension [y] | 1.6 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
LFXTAL082123
24 MHz ±10ppm Crystal 8pF 120 Ohms 4-SMD, No Lead
