SD2025M00012T1521006
ActiveHefei Jingweite Electronics Co., Ltd.
49S/SMD 25M 12PF 10 30 -20/70 25
Deep-Dive with AI
Search across all available documentation for this part.
SD2025M00012T1521006
ActiveHefei Jingweite Electronics Co., Ltd.
49S/SMD 25M 12PF 10 30 -20/70 25
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SD2025M00012T1521006 |
|---|---|
| ESR (Equivalent Series Resistance) | 20 Ohms |
| Frequency | 25 MHz |
| Frequency Stability | 30 ppm |
| Frequency Tolerance | 10 ppm |
| Height - Seated (Max) [Max] [z] | 4.1 mm |
| Height - Seated (Max) [Max] [z] | 0.161 " |
| Load Capacitance | 12 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 C |
| Package / Case | HC-49/US |
| Size / Dimension [x] | 0.449 " |
| Size / Dimension [x] | 11.4 mm |
| Size / Dimension [y] | 4.7 mm |
| Size / Dimension [y] | 0.185 in |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1000 | $ 0.14 | |
| 2000 | $ 0.13 | |||
| 3000 | $ 0.12 | |||
| 5000 | $ 0.12 | |||
| 7000 | $ 0.11 | |||
| 10000 | $ 0.11 | |||
| 25000 | $ 0.10 | |||
| 50000 | $ 0.09 | |||
| 100000 | $ 0.09 | |||
Description
General part information
SD2025M00012T1521006
25 MHz ±10ppm Crystal 12pF 20 Ohms HC-49/US
