24518
UnknownSchott Corporation
FIXED IND 100UH 2.1A 90 MOHM SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 24518 |
|---|---|
| Current - Saturation (Isat) | 1.77 A |
| Current Rating (Amps) | 2.1 A |
| DC Resistance (DCR) [Max] | 90 mOhm |
| Height - Seated (Max) [Max] [z] | 8 mm |
| Height - Seated (Max) [Max] [z] | 0.315 in |
| Inductance | 100 µH |
| Inductance Frequency - Test | 10 kHz |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension [x] | 0.895 in |
| Size / Dimension [x] | 22.73 mm |
| Size / Dimension [y] | 0.66 " |
| Size / Dimension [y] | 16.76 mm |
| Tolerance | 10 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 3.68 | |
| 10 | $ 3.57 | |||
| 25 | $ 3.52 | |||
| 50 | $ 3.49 | |||
| 100 | $ 3.46 | |||
Description
General part information
24518
100 µH Unshielded Inductor 2.1 A 90mOhm Max Nonstandard
Documents
Technical documentation and resources
No documents available
