Technical Specifications
Parameters and characteristics for this part
| Specification | I-2FOM38SL15-MC |
|---|---|
| 1st Connector | SC |
| 2nd Connector | ST |
| Bend Radius [radius] | 10 mm |
| Cable Diameter [diameter] | 2 mm |
| Cable Diameter [diameter] | 0.08 in |
| Cable Type | Fiber Patch |
| Color - Connectors | Beige |
| Features | Plenum, Riser |
| Fiber Type | OM3 |
| Insertion Loss | 0.3 dB |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Length - Overall [x] | 15 m |
| Length - Overall [x] | 49.2 ' |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 C |
| Ratings | OFNR, OFNP |
| Return Loss | 55 dB |
| Type | Duplex, OM3, Multimode |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Box (TB) | 1 | $ 91.00 | |
| 1 | $ 91.00 | |||
| 1 | $ 91.00 | |||
| 1 | $ 91.00 | |||
| 10 | $ 86.45 | |||
| 10 | $ 89.00 | |||
| 10 | $ 86.45 | |||
| 10 | $ 89.00 | |||
| 25 | $ 87.00 | |||
| 25 | $ 82.13 | |||
| 25 | $ 87.00 | |||
| 25 | $ 82.13 | |||
| 50 | $ 78.02 | |||
| 50 | $ 85.00 | |||
| 50 | $ 78.02 | |||
| 50 | $ 85.00 | |||
Description
General part information
I-2FOM38SL15-MC
Cable Fiber Optic SC To ST OM3 49.2' (15.0m)
