39151
ActiveAnamet Electrical
HCX EXTREME TEMP CONDUIT , 1 1/2
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
39151
ActiveAnamet Electrical
HCX EXTREME TEMP CONDUIT , 1 1/2
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 39151 |
|---|---|
| Color | Black |
| Diameter - Inside [diameter] | 1.6 in |
| Diameter - Inside [diameter] | 40.64 mm |
| Diameter - Outside [diameter] | 48.26 mm |
| Diameter - Outside [diameter] | 1.9 " |
| Heat Protection | Heat Resistant |
| Length | 15.24 m |
| Length [x] | 50 ft |
| Liquid Protection | Oil Resistant |
| Material | Thermoplastic Rubber |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -60 °C |
| Type | Protective Hose, Wire Loom |
| Type Attributes | Convoluted, Square Lock |
| Wall Thickness | 7.62 mm |
| Wall Thickness | 0.3 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 23.77 | |
| Tape & Box (TB) | 1 | $ 2099.85 | ||
Description
General part information
39151
Black Thermoplastic Rubber Convoluted, Square Lock Wire Loom, Protective Hose 1.600" (40.64mm) 50.00' (15.24m)
