CD035M331G10PE50V00A
ActiveSuscon
CAP ALUM 330UF 20% 35V SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CD035M331G10PE50V00A
ActiveSuscon
CAP ALUM 330UF 20% 35V SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CD035M331G10PE50V00A |
|---|---|
| Applications | Automotive |
| Capacitance | 330 µF |
| Height - Seated (Max) [Max] | 0.394 in |
| Height - Seated (Max) [Max] | 10 mm |
| Lifetime @ Temp. | 2000 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Radial, Can - SMD |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current @ High Frequency | 850 mA |
| Ripple Current @ Low Frequency | 510 mA |
| Size / Dimension [diameter] | 10 mm |
| Size / Dimension [diameter] | 0.394 in |
| Surface Mount Land Size [x] | 0.406 in |
| Surface Mount Land Size [x] | 10.3 mm |
| Surface Mount Land Size [y] | 10.3 mm |
| Surface Mount Land Size [y] | 0.406 " |
| Tolerance | 20 % |
| Voltage - Rated | 35 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 5 | $ 0.41 | |
| 50 | $ 0.34 | |||
| 100 | $ 0.29 | |||
| 500 | $ 0.25 | |||
| 1000 | $ 0.22 | |||
Description
General part information
CD035M331G10PE50V00A
330 µF 35 V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 105°C
