2-8940-125
ActiveTelevac
SENSOR 0PSIG 10V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
2-8940-125
ActiveTelevac
SENSOR 0PSIG 10V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 2-8940-125 |
|---|---|
| Accuracy | 30 % |
| Maximum Pressure [Max] | 1034.21 kPa |
| Maximum Pressure [Max] | 150 PSI |
| Operating Pressure | 0.13 PSI |
| Operating Pressure | 0.93 kPa |
| Output [Max] | 10 V |
| Output [Min] | 0 mV |
| Output Type | Analog Voltage |
| Package / Case | Module |
| Pressure Type | Gauge |
| Termination Style | Connector |
| Voltage - Supply [Max] | 26 V |
| Voltage - Supply [Min] | 22 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 2031.25 | |
| 10 | $ 1929.69 | |||
Description
General part information
2-8940-125
Pressure Sensor 0.13PSI (0.93kPa) Gauge 0 V ~ 10 V Module
Documents
Technical documentation and resources
