RISH CON-CV-AVG-14-F-V-02-L
ActiveRishabh Instruments
VOLTAGE TRANSDUCER 0~500V I/P
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | RISH CON-CV-AVG-14-F-V-02-L |
|---|---|
| Approval Agency | UL |
| Input Range [Max] | 500 VAC |
| Input Range [Min] | 0 VAC |
| Mounting Type | DIN Rail |
| Operating Temperature [Max] | 45 °C |
| Operating Temperature [Min] | 0 °C |
| Output [Max] | 5 V |
| Output [Min] | 0 mV |
| Response Time | 250 ms |
| Termination Style | Screw Terminal |
| Type | Voltage Transducer |
| Voltage - Supply [Max] | 60 VAC |
| Voltage - Supply [Min] | 24 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 33.00 | |
Description
General part information
RISH CON-CV-AVG-14-F-V-02-L
Voltage Transducer 0 ~ 500VAC Input 0 ~ 5VDC Output 24 ~ 60VAC/DC DIN Rail
Documents
Technical documentation and resources
No documents available
