IPSPS-1-BK-T5-UL
ActiveSure-Seal
PANEL SOURCE L1 BLACK 455A
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
IPSPS-1-BK-T5-UL
ActiveSure-Seal
PANEL SOURCE L1 BLACK 455A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | IPSPS-1-BK-T5-UL |
|---|---|
| Applications | Industrial |
| Color | Black |
| Connector Type | Plug, Male Pins |
| Contact Finish - Mating | Silver |
| Current Rating (Amps) | 800 A |
| Fastening Type | Bayonet Lock |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | Flange |
| Number of Positions | 1 |
| Primary Material | Plastic |
| Termination | Threaded |
| Voltage Rating | 1000 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 43.04 | |
| 10 | $ 39.12 | |||
| 25 | $ 37.75 | |||
| 50 | $ 35.86 | |||
| 100 | $ 34.71 | |||
Description
General part information
IPSPS-1-BK-T5-UL
1 Position Circular Connector Plug, Male Pins Threaded
