PEAMD150-12
ActiveTT Electronics/Power Partners Inc.
AC/DC DESKTOP ADAPTER 12V 150W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PEAMD150-12
ActiveTT Electronics/Power Partners Inc.
AC/DC DESKTOP ADAPTER 12V 150W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PEAMD150-12 |
|---|---|
| Applications | Medical |
| Approval Agency | CE, cURus |
| Current - Output (Max) [Max] | 12.5 A |
| Efficiency | Level VI |
| Form | Desktop (Class I) |
| Input Connector | IEC 320-C14 |
| Input Type | Cord |
| No Load Power Consumption | 210 mW |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | 0 °C |
| Output Connector | 4 Pin |
| Output Connector | Power DIN |
| Power (Watts) | 150 W |
| Region Utilized | International |
| Size / Dimension [x] | 7.05 in |
| Size / Dimension [x] | 179 mm |
| Size / Dimension [y] | 2.56 " |
| Size / Dimension [y] | 65 mm |
| Size / Dimension [z] | 1.57 " |
| Size / Dimension [z] | 40 mm |
| Standard Number | 60601-1 |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Output | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 56.39 | |
| 5 | $ 52.51 | |||
Description
General part information
PEAMD150-12
12V 150 W AC/DC External Desktop (Class I) Adapter Cord (Sold Separately) Input
