Technical Specifications
Parameters and characteristics for this part
| Specification | HMD8709D-20M4000 |
|---|---|
| Applications | General Purpose |
| Coupler Type | Dual Band, Dual Path |
| Coupling Factor | 20 dB |
| Frequency [Max] | 5 GHz |
| Frequency [Min] | 3.3 GHz |
| Insertion Loss | 0.07 dB |
| Package / Case | 0805 (2012 Metric) |
| Package / Case | 6 Leads |
| Power - Max [Max] | 10 W |
| Return Loss | 24.6 dB |
| Supplier Device Package | 0805 |
