UC2526J
ActiveUnitrode
SWITCHING CONTROLLER, VOLTAGE-MO
Deep-Dive with AI
Search across all available documentation for this part.
UC2526J
ActiveUnitrode
SWITCHING CONTROLLER, VOLTAGE-MO
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | UC2526J |
|---|---|
| Clock Sync | True |
| Control Features | Enable, Frequency Control, Soft Start, Reset |
| Duty Cycle (Max) | 49 % |
| Frequency - Switching [Max] | 400 kHz |
| Frequency - Switching [Min] | 1 Hz |
| Function | Step-Up, Step-Up/Step-Down |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 C |
| Operating Temperature [Min] | -25 °C |
| Output Configuration | Positive |
| Output Phases | 1 |
| Output Type | Transistor Driver |
| Package / Case | 18-CDIP |
| Package / Case | 7.62 mm |
| Package / Case | 0.3 in |
| Supplier Device Package | 18-CDIP |
| Synchronous Rectifier | True |
| Topology | Forward Converter, Full-Bridge, Flyback, Half-Bridge, Boost, Push-Pull |
| Voltage - Supply (Vcc/Vdd) [Max] | 35 V |
| Voltage - Supply (Vcc/Vdd) [Min] | 8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 41 | $ 7.49 | |
Description
General part information
UC2526J
Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 18-CDIP
