MPS-3003H-3
ActiveMATRIX TECHNOLOGY INC.
HI-PREC 3CH LINEAR DC PWR SUPPLY
Deep-Dive with AI
Search across all available documentation for this part.
MPS-3003H-3
ActiveMATRIX TECHNOLOGY INC.
HI-PREC 3CH LINEAR DC PWR SUPPLY
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MPS-3003H-3 |
|---|---|
| Current - Output | 0 A, 3 A |
| Current - Output [Max] | 3 A |
| Current - Output [Min] | 0 A |
| Current Regulation - Line | 5 mA, 0.1 % |
| Current Regulation - Load | 5 mA, 0.1 % |
| Number of Characters | 16 |
| Number of Outputs | 3 |
| Ripple | 2 mV, 5 mV rms |
| Type | Bench (AC to DC) |
| Voltage Regulation - Line | 5 mV, 0.01 % |
| Voltage Regulation - Load | 5 mV, 0.01 % |
| Weight | 19.8 lbs |
| Weight | 9 kg |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 317.00 | |
Description
General part information
MPS-3003H-3
0V, 0 ~ 5V, 30V, 30V Output Bench (AC to DC) Power Supply 0A, 0 ~ 3A, 3A, 3A Output Features Adjustable, Memory, Encoder, Regulated, OVP/OCP
