280-D30N3XC
Activec3controls
3 POLE, 30A, 24V AC (50/60 HZ)
Deep-Dive with AI
Search across all available documentation for this part.
280-D30N3XC
Activec3controls
3 POLE, 30A, 24V AC (50/60 HZ)
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 280-D30N3XC |
|---|---|
| Coil Current | 3.4 A |
| Coil Power | 82.29 W |
| Coil Resistance | 7 Ohms |
| Coil Voltage | 24 VAC |
| Contact Form | 3PST-NO (3 Form A) |
| Contact Rating (Current) | 30 A |
| Features | Insulation - Class B |
| Mounting Type | Chassis Mount |
| Must Operate Voltage | 18 VAC |
| Must Release Voltage | 6 VAC |
| Operating Temperature [Max] | 65 °C |
| Operating Temperature [Min] | -40 °C |
| Switching Voltage [Max] | 277 VAC |
| Termination Style | Screw Terminal, Quick Connect |
| Termination Style | 0.25 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Box (TB) | 1 | $ 8.47 | |
Description
General part information
280-D30N3XC
3 POLE, 30A, 24V AC (50/60 HZ)
