ETSB25E004800E
ActiveHosonic Electronic Co., Ltd
XTAL 1612 25MHZ,8P
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ETSB25E004800E
ActiveHosonic Electronic Co., Ltd
XTAL 1612 25MHZ,8P
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ETSB25E004800E |
|---|---|
| ESR (Equivalent Series Resistance) | 100 Ohms |
| Frequency | 25 MHz |
| Frequency Stability | 15 ppm |
| Frequency Tolerance | 10 ppm |
| Height - Seated (Max) [Max] [z] | 0.5 mm |
| Height - Seated (Max) [Max] [z] | 0.02 " |
| Load Capacitance | 8 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 1.6 mm |
| Size / Dimension [x] | 0.063 in |
| Size / Dimension [y] | 0.047 in |
| Size / Dimension [y] | 1.2 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.00 | |
| 10 | $ 0.88 | |||
| 50 | $ 0.83 | |||
| 100 | $ 0.73 | |||
| 500 | $ 0.69 | |||
| 1000 | $ 0.58 | |||
| Digi-Reel® | 1 | $ 1.00 | ||
| 10 | $ 0.88 | |||
| 50 | $ 0.83 | |||
| 100 | $ 0.73 | |||
| 500 | $ 0.69 | |||
| 1000 | $ 0.58 | |||
| Tape & Reel (TR) | 3000 | $ 0.56 | ||
| 6000 | $ 0.54 | |||
| 15000 | $ 0.52 | |||
Description
General part information
ETSB25E004800E
25 MHz ±10ppm Crystal 8pF 100 Ohms 4-SMD, No Lead
