Technical Specifications
Parameters and characteristics for this part
| Specification | CF297 T2206C |
|---|---|
| Core Type | Toroid |
| Diameter [diameter] | 22.35 mm |
| Diameter [diameter] | 0.88 in |
| Finish | Epoxy |
| Height [z] | 6.75 mm |
| Height [z] | 0.265 in |
| Material | 3C90 |
| Supplier Device Package | TX |
| Supplier Device Package [x] | 22 |
| Supplier Device Package [y] | 14 |
| Supplier Device Package [z] | 6.4 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 50 | $ 1.10 | |
Description
General part information
CF297 T2206C
Epoxy 3C90 Ferrite Core Toroid Type Length Width 0.880" (22.35mm) Diameter 0.265" (6.75mm) Height
