E3SB10E000007E
ActiveHosonic Electronic Co., Ltd
XTAL 3225 10MHZ, 12PF
Deep-Dive with AI
Search across all available documentation for this part.
E3SB10E000007E
ActiveHosonic Electronic Co., Ltd
XTAL 3225 10MHZ, 12PF
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | E3SB10E000007E |
|---|---|
| ESR (Equivalent Series Resistance) | 150 Ohms |
| Frequency | 10 MHz |
| Frequency Stability | 30 ppm |
| Frequency Tolerance | 30 ppm |
| Height - Seated (Max) [Max] [z] | 0.03 in |
| Height - Seated (Max) [Max] [z] | 0.75 mm |
| Load Capacitance | 12 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 3.2 mm |
| Size / Dimension [x] | 0.126 in |
| Size / Dimension [y] | 2.5 mm |
| Size / Dimension [y] | 0.098 in |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.36 | |
| 10 | $ 0.30 | |||
| 50 | $ 0.27 | |||
| 100 | $ 0.24 | |||
| 500 | $ 0.23 | |||
| 1000 | $ 0.19 | |||
| Digi-Reel® | 1 | $ 0.37 | ||
| 10 | $ 0.32 | |||
| 50 | $ 0.29 | |||
| 100 | $ 0.28 | |||
| 500 | $ 0.25 | |||
| 1000 | $ 0.24 | |||
| Tape & Reel (TR) | 3000 | $ 0.18 | ||
| 6000 | $ 0.18 | |||
| 15000 | $ 0.17 | |||
Description
General part information
E3SB10E000007E
10 MHz ±30ppm Crystal 12pF 150 Ohms 4-SMD, No Lead
Documents
Technical documentation and resources
No documents available
