CCT13W500
ActiveMagnitude Lighting
13W 500MA DIMMBLE CC LED DRIVER
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CCT13W500
ActiveMagnitude Lighting
13W 500MA DIMMBLE CC LED DRIVER
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CCT13W500 |
|---|---|
| Approval Agency | CSA, UL |
| Current - Output (Max) [Max] | 500 mA |
| Dimming | MLV, ELV, TRIAC |
| Features | SS, OVP, OTP, OCP |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -30 ░C |
| Power (Watts) | 13 W |
| Ratings | IP20 |
| Size / Dimension [diameter] | 2.56 in |
| Size / Dimension [diameter] | 65 mm |
| Size / Dimension [z] | 1.06 in |
| Size / Dimension [z] | 27 mm |
| Standard Number | C22.2, UL 8750 |
| Termination Style | Wire Leads |
| Topology | Buck |
| Type | Constant Current |
| Voltage - Input (Max) [Max] | 120 VAC |
| Voltage - Input (Min) [Min] | 100 VAC |
| Voltage - Output [Max] | 26 V |
| Voltage - Output [Min] | 18 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 28.38 | |
| 5 | $ 27.09 | |||
| 10 | $ 25.80 | |||
Description
General part information
CCT13W500
500mA 18 ~ 26V Constant Current LED Driver Buck Topology 1 Output
