EDT230030R
ActivenVent
SPD 300V MCOV 1 POLE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
EDT230030R
ActivenVent
SPD 300V MCOV 1 POLE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | EDT230030R |
|---|---|
| Approval Agency | cUR, UR, CE, VDE |
| Current - Discharge (Max) (8/20µS) [Max] | 50 kA |
| Current - Discharge (Nom) (8/20µS) | 20 kA |
| Current - Short Circuit Rating (SCCR) | 25 kA |
| Features | Remote Signaling Contacts |
| Form | Base + Module |
| Mounting Type | DIN Rail |
| Number of Poles | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -35 °C |
| Voltage - Continuous Operating (Max) (MCOV) [Max] | 300 V |
| Voltage - Protection Level (VP) (2416) | 1.65 kV |
| Voltage - Protection Rating (VPR) | 1.2 kV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Retail Package | 5 | $ 468.36 | |
Description
General part information
EDT230030R
SPD 300V MCOV 1 POLE
Documents
Technical documentation and resources
