400HXK330MEPASN22X45
ActiveRubycon
CAP ALUM 330UF 20% 400V SNAP TH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
400HXK330MEPASN22X45
ActiveRubycon
CAP ALUM 330UF 20% 400V SNAP TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 400HXK330MEPASN22X45 |
|---|---|
| Applications | Automotive |
| Capacitance | 330 µF |
| Height - Seated (Max) [Max] [z] | 1.85 in |
| Height - Seated (Max) [Max] [z] | 47 mm |
| Lead Spacing | 0.394 in |
| Lead Spacing | 10 mm |
| Lifetime @ Temp. | 5000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Radial, Can - Snap-In |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current @ High Frequency | 2.394 A |
| Ripple Current @ Low Frequency | 1.71 A |
| Size / Dimension [diameter] | 22 mm |
| Size / Dimension [diameter] | 0.866 in |
| Tolerance | 20 % |
| Voltage - Rated | 400 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 9.10 | |
| 10 | $ 6.44 | |||
| 50 | $ 5.40 | |||
| 200 | $ 5.08 | |||
| 600 | $ 4.55 | |||
| 1000 | $ 4.39 | |||
Description
General part information
400HXK330MEPASN22X45
330 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 5000 Hrs @ 105°C
