YC4032M00033T1521023
ActiveHefei Jingweite Electronics Co., Ltd.
XTAL OSC XO 32.0000MHZ CMOS SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
YC4032M00033T1521023
ActiveHefei Jingweite Electronics Co., Ltd.
XTAL OSC XO 32.0000MHZ CMOS SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | YC4032M00033T1521023 |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Disable) (Max) [Max] | 10 ÁA |
| Current - Supply (Max) [Max] | 10 mA |
| Frequency | 32 MHz |
| Function | Enable/Disable |
| Height - Seated (Max) | 1.35 mm |
| Height - Seated (Max) [Max] [z] | 0.053 in |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output | CMOS |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 0.197 in |
| Size / Dimension [x] | 5 mm |
| Size / Dimension [y] | 0.126 " |
| Size / Dimension [y] | 3.2 mm |
| Type | XO (Standard) |
| Voltage - Supply | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Case | 1 | $ 1.57 | |
| 10 | $ 1.20 | |||
| 25 | $ 1.08 | |||
| 50 | $ 0.99 | |||
| 100 | $ 0.92 | |||
| 250 | $ 0.83 | |||
| 500 | $ 0.77 | |||
| 1000 | $ 0.72 | |||
| 2500 | $ 0.65 | |||
Description
General part information
YC4032M00033T1521023
32 MHz XO (Standard) CMOS Oscillator 3.3V Enable/Disable 4-SMD, No Lead
