XGZP6899A001KPDPN
ActiveCFSensor
PRESSURE SENSOR 0.145PSI(-1~1KPA
Deep-Dive with AI
Search across all available documentation for this part.
XGZP6899A001KPDPN
ActiveCFSensor
PRESSURE SENSOR 0.145PSI(-1~1KPA
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | XGZP6899A001KPDPN |
|---|---|
| Accuracy | 2.5 % |
| Applications | Board Mount |
| Features | Temperature Compensated, Amplified Output |
| Maximum Pressure | 0.73 PSI |
| Maximum Pressure | 5 kPa |
| Mounting Type | Surface Mount |
| Operating Pressure [Max] | 1 kPa |
| Operating Pressure [Min] | -1 kPa |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -20 C |
| Output [Max] | 4.5 V |
| Output [Min] | 0.5 V |
| Output Type | Analog |
| Package / Case | Dual Ports, Same Side, 8-SMD, Gull Wing |
| Port Size | 0.12 " |
| Port Size | Male, Tube, Dual |
| Port Size | 3 mm |
| Port Style | Barbed |
| Pressure Type | Differential |
| Supplier Device Package | 8-SMT |
| Termination Style | Surface Mount (SMD,SMT) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 3 | $ 10.20 | |
| 9 | $ 9.78 | |||
| 24 | $ 9.35 | |||
| 102 | $ 8.93 | |||
| 501 | $ 8.50 | |||
Description
General part information
XGZP6899A001KPDPN
Pressure Sensor -0.144PSI ~ 0.144PSI (-1.0kPa ~ 1.0kPa) Differential Male - 0.12" (3mm) Tube, Dual 0.5 V ~ 4.5 V 8-SMD, Gull Wing, Dual Ports, Same Side
