G07F1E152MN0B0S0N0
ActiveSongtian Electronics Co., Ltd
CAP CER 1500PF 250V Y5V RADIAL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
G07F1E152MN0B0S0N0
ActiveSongtian Electronics Co., Ltd
CAP CER 1500PF 250V Y5V RADIAL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | G07F1E152MN0B0S0N0 |
|---|---|
| Applications | Safety |
| Capacitance | 1500 pF |
| Height - Seated (Max) [Max] | 9.5 mm |
| Height - Seated (Max) [Max] | 0.374 in |
| Lead Spacing | 0.394 in |
| Lead Spacing | 10 mm |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | Disc, Radial |
| Ratings [custom] | 2 |
| Ratings [custom] | 1 |
| Size / Dimension [diameter] | 4 mm |
| Size / Dimension [diameter] | 0.157 in |
| Temperature Coefficient | Y5V (F) |
| Tolerance | 20 % |
| Voltage - Rated | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 0.55 | |
| 10 | $ 0.33 | |||
| 50 | $ 0.24 | |||
| 100 | $ 0.21 | |||
| 500 | $ 0.17 | |||
| 1000 | $ 0.15 | |||
| 2500 | $ 0.14 | |||
| 5000 | $ 0.13 | |||
Description
General part information
G07F1E152MN0B0S0N0
1500 pF ±20% 250V Ceramic Capacitor Y5V (F) Radial, Disc
Documents
Technical documentation and resources
