Technical Specifications
Parameters and characteristics for this part
| Specification | VTX-146-160-115 |
|---|---|
| Center Tap | False |
| Current - Output (Max) [Max] | 5.33 A |
| Height - Seated (Max) [Max] [z] | 46 mm |
| Mounting Type | Chassis Mount |
| Power - Max [Max] | 160 VA |
| Primary Winding(s) | Single |
| Secondary Winding(s) | Dual |
| Size / Dimension [diameter] | 105 mm |
| Termination Style | Wire Leads |
| Type | Toroidal |
| Voltage - Isolation | 4200 Vrms |
| Voltage - Primary | 230 V |
| Voltage - Secondary (Full Load) | 30 V, 15 V |
| Weight | 1.6 kg |
| Weight | 3.6 lbs |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 40.00 | |
Description
General part information
VTX-146-160-115
PWR XFMR TOROIDAL 160VA CHAS MT
