ES1-F20
ActiveDIT
LINE FILTER 250VAC/VDC 20A CHASS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ES1-F20
ActiveDIT
LINE FILTER 250VAC/VDC 20A CHASS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ES1-F20 |
|---|---|
| Applications | General Purpose |
| Approval Agency | CQC, UR, CSA, TUV |
| Configuration | Single Stage |
| Current | 20 A |
| Filter Type | Single Phase |
| Frequency - Operating [Max] | 60 Hz |
| Frequency - Operating [Min] | 50 Hz |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -25 °C |
| Termination Style | Quick Connect |
| Voltage - Rated AC | 250 V |
| Voltage - Rated DC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 17.09 | |
| 20 | $ 13.83 | |||
| 40 | $ 13.17 | |||
| 60 | $ 12.80 | |||
| 100 | $ 12.34 | |||
| 260 | $ 11.54 | |||
| 500 | $ 11.02 | |||
Description
General part information
ES1-F20
Single Phase EMC/EMI Line Filter 20 A 250V 250V 50 ~ 60Hz Single Stage Quick Connect
Documents
Technical documentation and resources
