AMC-LS 100A 170V (PF)
ActiveConquer
POWER FUSE, 14.6*22.3MM, 100A, 1
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AMC-LS 100A 170V (PF)
ActiveConquer
POWER FUSE, 14.6*22.3MM, 100A, 1
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AMC-LS 100A 170V (PF) |
|---|---|
| Applications | Telecom |
| Breaking Capacity @ Rated Voltage | 100 kA |
| Current Rating (Amps) | 100 A |
| Features | Clips Included |
| Fuse Type | Cartridge |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Radial Bend Cylinder |
| Response Time | Fast Blow |
| Size / Dimension [diameter] | 0.575 ", 14.6 mm |
| Size / Dimension [z] | 0.88 in, 22.36 mm |
| Voltage Rating - DC | 170 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 27.40 | |
| 5 | $ 22.82 | |||
| 10 | $ 21.09 | |||
| 50 | $ 17.54 | |||
| 100 | $ 16.18 | |||
| 250 | $ 14.55 | |||
| 500 | $ 13.41 | |||
Description
General part information
AMC-LS 100A 170V (PF)
100A 170 VDC Fuse Cartridge Through Hole
