S1A-404017
ActiveNew Age Enclosures
BOX ABS WHITE 4"L X 4"W
Deep-Dive with AI
Search across all available documentation for this part.
S1A-404017
ActiveNew Age Enclosures
BOX ABS WHITE 4"L X 4"W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | S1A-404017 |
|---|---|
| Area (L x W) | 16 in˛ |
| Area (L x W) | 103 cm˛ |
| Color | White |
| Container Type | Box |
| Design | Cover Included, Hand Held |
| Height [z] | 1.598 in |
| Height [z] | 40.59 mm |
| Material | Plastic, ABS |
| Size / Dimension [x] | 4 in |
| Size / Dimension [x] | 101.6 mm |
| Size / Dimension [y] | 101.6 mm |
| Size / Dimension [y] | 4 " |
| Thickness [x] | 1.57 mm |
| Thickness [x] | 0.062 " |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 10.22 | |
| 5 | $ 8.73 | |||
| 10 | $ 8.16 | |||
| 25 | $ 7.46 | |||
| 50 | $ 6.97 | |||
| 100 | $ 6.52 | |||
| 250 | $ 6.01 | |||
Description
General part information
S1A-404017
Box Plastic, ABS White Hand Held, Cover Included 4.000" L x 4.000" W (101.60mm x 101.60mm) X 1.598" (40.59mm)
Documents
Technical documentation and resources
No documents available
