SR612-N
ActiveMagnitude Lighting
SR 8W 12V AC/DC 6VDC - 12VDC REC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SR612-N
ActiveMagnitude Lighting
SR 8W 12V AC/DC 6VDC - 12VDC REC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SR612-N |
|---|---|
| Current - Output (Max) [Max] | 600 mA |
| Dimming | TRIAC |
| Efficiency | 87 % |
| Features | OVP, UVLO, OCP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 40 °C |
| Operating Temperature [Min] | -30 ░C |
| Power (Watts) | 8 W |
| Ratings | IP67 |
| Size / Dimension [diameter] | 25 mm |
| Size / Dimension [diameter] | 0.98 " |
| Size / Dimension [x] | 19 mm |
| Size / Dimension [x] | 0.74 in |
| Termination Style | Wire Leads |
| Topology | Buck |
| Type | Constant Current |
| Voltage - Input (Max) [Max] | 15 V |
| Voltage - Input (Min) [Min] | 9 V |
| Voltage - Output [Max] | 12 V |
| Voltage - Output [Min] | 6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 36.16 | |
| 5 | $ 34.52 | |||
| 10 | $ 32.88 | |||
Description
General part information
SR612-N
600mA 6 ~ 12V Constant Current LED Driver Buck Topology 1 Output
