MC53113
ActivePerformance Motion Devices, Inc.
MAGELLAN BLDC CTRL IC, 1-AXIS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MC53113
ActivePerformance Motion Devices, Inc.
MAGELLAN BLDC CTRL IC, 1-AXIS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MC53113 |
|---|---|
| Applications | Industrial, General Purpose, Automation Control, Medical |
| Current - Output | 4 mA |
| Function | Controller - Commutation, Current Management, Direction Management |
| Interface | SPI, CAN, RS-232, RS-485 |
| Motor Type - AC, DC | Brushless DC (BLDC), PMSM, Servo |
| Motor Type - Stepper | Multiphase |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | High Side, Low Side |
| Package / Case | 100-LQFP |
| Supplier Device Package | 100-TQFP (14x14) |
| Technology | CMOS |
| Voltage - Supply [Max] | 3.63 V |
| Voltage - Supply [Min] | 2.97 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 79.95 | |
| 10 | $ 63.51 | |||
| 25 | $ 59.32 | |||
| 80 | $ 57.81 | |||
Description
General part information
MC53113
Multiphase Motor Driver CMOS CAN, RS-232, RS-485, SPI 100-TQFP (14x14)
