Y116964K0000B0R
ActiveVPG Foil Resistors
RES SMD 64K OHM 0.1% 0.4W J LEAD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
Y116964K0000B0R
ActiveVPG Foil Resistors
RES SMD 64K OHM 0.1% 0.4W J LEAD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | Y116964K0000B0R |
|---|---|
| Features | Pulse Withstanding, Non-Inductive, Moisture Resistant |
| Height - Seated (Max) [Max] [z] | 0.122 " |
| Height - Seated (Max) [Max] [z] | 3.1 mm |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 347 °F |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 3017 J-Lead |
| Power (Watts) | 0.4 W |
| Power (Watts) | 0.4 W |
| Resistance | 64 kOhms |
| Size / Dimension [x] | 0.287 in, 7.29 mm |
| Size / Dimension [y] | 4.32 mm, 0.17 in |
| Supplier Device Package | SMD |
| Temperature Coefficient | 2 ppm/°C |
| Tolerance | 0.1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1000 | $ 10.13 | |
Description
General part information
Y116964K0000B0R
64 kOhms ±0.1% 0.4W, 2/5W Chip Resistor 3017 J-Lead Moisture Resistant, Non-Inductive, Pulse Withstanding Metal Foil
