XZDG155W5MAV
ActiveSunLED
LED GREEN CLEAR 2SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
XZDG155W5MAV
ActiveSunLED
LED GREEN CLEAR 2SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | XZDG155W5MAV |
|---|---|
| Color | Green |
| Current - Test | 5 mA |
| Height (Max) [Max] | 0.25 mm |
| Lens Color | Colorless |
| Lens Size [x] | 0.65 mm |
| Lens Size [y] | 0.35 mm |
| Lens Style | Rectangle with Flat Top |
| Lens Transparency | Clear |
| Millicandela Rating | 278 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 0603 Metric |
| Package / Case | 0201 |
| Size / Dimension [x] | 0.65 mm |
| Size / Dimension [y] | 0.35 mm |
| Supplier Device Package | 2-SMD |
| Viewing Angle | 140 ° |
| Voltage - Forward (Vf) (Typ) | 2.85 V |
| Wavelength - Dominant | 525 nm |
| Wavelength - Peak | 515 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.64 | |
| 10 | $ 0.40 | |||
| 100 | $ 0.23 | |||
| 1000 | $ 0.18 | |||
| 2000 | $ 0.16 | |||
| Digi-Reel® | 1 | $ 0.64 | ||
| 10 | $ 0.40 | |||
| 100 | $ 0.23 | |||
| 1000 | $ 0.18 | |||
| 2000 | $ 0.16 | |||
| Tape & Reel (TR) | 4000 | $ 0.16 | ||
| 8000 | $ 0.15 | |||
| 12000 | $ 0.14 | |||
| 28000 | $ 0.13 | |||
Description
General part information
XZDG155W5MAV
Green 525nm LED Indication - Discrete 2.85V 0201 (0603 Metric)
