Technical Specifications
Parameters and characteristics for this part
| Specification | XQS11N3R9B |
|---|---|
| Applications | High Frequency, Microwave, RF |
| Capacitance | 3.9 pF |
| Features | High Q |
| Mounting Type | Surface Mount, MLCC |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 1111 (2828 Metric) |
| Size / Dimension [x] | 2.79 mm |
| Size / Dimension [x] | 0.11 in |
| Size / Dimension [y] | 0.11 in |
| Size / Dimension [y] | 2.79 mm |
| Temperature Coefficient | NP0, C0G |
| Thickness (Max) | 1.78 mm |
| Thickness (Max) [Max] | 0.07 in |
| Tolerance | 0.1 pF |
| Voltage - Rated | 500 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1 | $ 4.80 | |
| 10 | $ 3.43 | |||
| 50 | $ 2.06 | |||
| 100 | $ 1.71 | |||
Description
General part information
XQS11N3R9B
3.9 pF ±0.1pF 500V Ceramic Capacitor C0G, NP0 1111 (2828 Metric)
