6M20P2/49SMT
ActiveYIC
CRYSTAL 6.0000MHZ 20PF SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
6M20P2/49SMT
ActiveYIC
CRYSTAL 6.0000MHZ 20PF SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 6M20P2/49SMT |
|---|---|
| ESR (Equivalent Series Resistance) | 80 Ohm |
| Frequency | 6 MHz |
| Frequency Stability | 30 ppm |
| Frequency Tolerance | 30 ppm |
| Height - Seated (Max) | 4.2 mm |
| Height - Seated (Max) [Max] | 0.165 in |
| Load Capacitance | 20 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 C |
| Package / Case | HC-49/US |
| Size / Dimension [x] | 11.4 mm |
| Size / Dimension [x] | 0.449 " |
| Size / Dimension [y] | 0.189 in |
| Size / Dimension [y] | 4.8 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.16 | |
| Digi-Reel® | 1 | $ 0.16 | ||
| Tape & Reel (TR) | 1000 | $ 0.16 | ||
Description
General part information
6M20P2/49SMT
6 MHz ±30ppm Crystal 20pF 80 Ohms HC-49/US
