SL10.104
ObsoletePULS, LP
AC/DC DIN RAIL SUPPLY 12V 180W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SL10.104
ObsoletePULS, LP
AC/DC DIN RAIL SUPPLY 12V 180W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SL10.104 |
|---|---|
| AC Voltage - Input [Max] | 264 VAC |
| AC Voltage - Input [Max] | 132 VAC |
| AC Voltage - Input [Min] | 176 VAC |
| AC Voltage - Input [Min] | 85 VAC |
| Applications | ITE (Commercial) |
| Approval Agency | cULus, CE, cURus, CB |
| Current - Output (Max) [Max] | 15 A |
| Efficiency | 87 % |
| Features | Adjustable Output |
| Input Type | AC |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Power (Watts) | 180 W |
| Size / Dimension [x] | 102 mm |
| Size / Dimension [x] | 4.02 in |
| Size / Dimension [y] | 4.72 in |
| Size / Dimension [y] | 120 mm |
| Size / Dimension [z] | 4.88 " |
| Size / Dimension [z] | 124 mm |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
SL10.104
AC/DC DIN RAIL SUPPLY 12V 180W
