PC785-1A-12S-R-X
ActivePicker Components
RELAY AUTOMOTIVE SPST 35A 12V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PC785-1A-12S-R-X
ActivePicker Components
RELAY AUTOMOTIVE SPST 35A 12V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PC785-1A-12S-R-X |
|---|---|
| Coil Current | 127.7 mA |
| Coil Power | 1.5 W |
| Coil Resistance | 94 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 12 VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Material | Silver Tin Oxide Indium Oxide (AgSnOInO) |
| Contact Rating (Current) | 35 A |
| Features | Resistor, Sealed - Fully |
| Mounting Type | Socketable |
| Must Operate Voltage | 7.2 VDC |
| Must Release Voltage | 1.2 VDC |
| Operate Time | 5 ms |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Release Time | 2 ms |
| Switching Voltage | 75 VDC |
| Termination Style | Plug In |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 2.47 | |
| 10 | $ 2.32 | |||
| 25 | $ 2.06 | |||
| 50 | $ 1.96 | |||
| 100 | $ 1.85 | |||
| 250 | $ 1.65 | |||
| 500 | $ 1.55 | |||
| 1000 | $ 1.44 | |||
| 5000 | $ 1.39 | |||
Description
General part information
PC785-1A-12S-R-X
RELAY AUTOMOTIVE SPST 35A 12V
