FIN1700E.018.M
ActiveEnerdoor
LINE FILTER 18A CHASSIS MOUNT
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FIN1700E.018.M
ActiveEnerdoor
LINE FILTER 18A CHASSIS MOUNT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FIN1700E.018.M |
|---|---|
| Applications | Medical |
| Approval Agency | UL, CSA, CE, cURus |
| Configuration | Two Stage |
| Current | 18 A |
| Filter Type | Three Phase (Delta) |
| Frequency - Operating [Max] | 60 Hz |
| Frequency - Operating [Min] | 50 Hz |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Termination Style | Terminal Block |
| Voltage - Rated AC (Phase to Ground/Neutral) | 3.1 kV |
| Voltage - Rated AC (Phase to Phase) | 2.3 kV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
FIN1700E.018.M
Three Phase (Delta) EMC/EMI Line Filter 18 A 50/60Hz Two Stage Terminal Block
Documents
Technical documentation and resources
