XTL501150-R53-028
ActiveSiward
CRYSTAL 2.0 X 1.6MM 40MHZ +/-5PP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
XTL501150-R53-028
ActiveSiward
CRYSTAL 2.0 X 1.6MM 40MHZ +/-5PP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | XTL501150-R53-028 |
|---|---|
| Frequency | 40 MHz |
| Frequency Stability | 15 ppm |
| Frequency Tolerance | ±5ppm |
| Height - Seated (Max) [Max] [z] | 0.022 in |
| Height - Seated (Max) [Max] [z] | 0.55 mm |
| Load Capacitance | 9 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 2 mm |
| Size / Dimension [x] | 0.079 in |
| Size / Dimension [y] | 0.063 in |
| Size / Dimension [y] | 1.6 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.48 | |
| 10 | $ 0.42 | |||
| 50 | $ 0.38 | |||
| 100 | $ 0.36 | |||
| 500 | $ 0.33 | |||
| Digi-Reel® | 1 | $ 0.48 | ||
| 10 | $ 0.42 | |||
| 50 | $ 0.38 | |||
| 100 | $ 0.36 | |||
| 500 | $ 0.33 | |||
| Tape & Reel (TR) | 1000 | $ 0.32 | ||
| 2000 | $ 0.30 | |||
| 3000 | $ 0.29 | |||
| 5000 | $ 0.29 | |||
| 7000 | $ 0.28 | |||
| 10000 | $ 0.27 | |||
| 25000 | $ 0.26 | |||
Description
General part information
XTL501150-R53-028
40 MHz ±5ppm Crystal 9pF 4-SMD, No Lead
