SDN2R7S6073572
ActiveYmin
SDN 600F 2.7V 35*72 -40~+70 1000
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SDN2R7S6073572
ActiveYmin
SDN 600F 2.7V 35*72 -40~+70 1000
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SDN2R7S6073572 |
|---|---|
| Capacitance | 600 F |
| Lead Spacing | 0.394 in |
| Lead Spacing | 10 mm |
| Lifetime @ Temp. | 1000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Radial, Can - Snap-In |
| Size / Dimension [diameter] | 1.378 in |
| Size / Dimension [diameter] | 35 mm |
| Termination | PC Pins |
| Tolerance [Max] | 30 % |
| Tolerance [Min] | -10 % |
| Voltage - Rated | 2.7 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 14.10 | |
| 10 | $ 13.04 | |||
| 50 | $ 11.28 | |||
| Tape & Reel (TR) | 100 | $ 10.15 | ||
| 200 | $ 9.64 | |||
| 300 | $ 9.39 | |||
| 500 | $ 9.10 | |||
| 700 | $ 8.94 | |||
| 1000 | $ 8.78 | |||
Description
General part information
SDN2R7S6073572
600 F (EDLC) Supercapacitor 2.7 V Radial, Can - Snap-In 1000 Hrs @ 70°C
Documents
Technical documentation and resources
