600-11005 - FT 10-RH-NS-K4
ActiveSensoPart
PHOTOELECTRIC DIFFUSE SENSOR WIT
Deep-Dive with AI
Search across all available documentation for this part.
600-11005 - FT 10-RH-NS-K4
ActiveSensoPart
PHOTOELECTRIC DIFFUSE SENSOR WIT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 600-11005 - FT 10-RH-NS-K4 |
|---|---|
| Adjustment Type | Teaching Method |
| Cable Length | 78.74 in |
| Cable Length | 2 m |
| Connection Method | Cable |
| Ingress Protection | IP67 |
| Light Source | RED (650nm) |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -20 C |
| Output Configuration | NPN |
| Response Time | 500 µs |
| Sensing Distance [Max] | 2.756 " |
| Sensing Distance [Max] | 70 mm |
| Sensing Distance [Min] | 0.197 in |
| Sensing Distance [Min] | 5 mm |
| Sensing Method | Diffuse, Background Suppression |
| Voltage - Supply [Max] | 30 VDC |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Retail Package | 1 | $ 180.00 | |
Description
General part information
600-11005 - FT 10-RH-NS-K4
Diffuse, Background Suppression Optical Sensor 0.197" ~ 2.756" (5mm ~ 70mm) NPN
Documents
Technical documentation and resources
No documents available
