JPAD100 TO-92 2L ROHS
ActiveLinear Integrated Systems, Inc.
DIODE GEN PURP 35V 10MA TO92
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
JPAD100 TO-92 2L ROHS
ActiveLinear Integrated Systems, Inc.
DIODE GEN PURP 35V 10MA TO92
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | JPAD100 TO-92 2L ROHS |
|---|---|
| Capacitance @ Vr, F | 1.5 pF |
| Current - Average Rectified (Io) | 10 mA |
| Current - Reverse Leakage @ Vr | 100 pA |
| Mounting Type | Through Hole |
| Operating Temperature - Junction [Max] | 150 °C |
| Operating Temperature - Junction [Min] | -55 °C |
| Package / Case | TO-92-2, TO-226-2 |
| Package / Case | TO-226AC |
| Speed | Any Speed |
| Speed | 200 mA |
| Supplier Device Package | TO-92 |
| Technology | Standard |
| Voltage - DC Reverse (Vr) (Max) [Max] | 35 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 4.36 | |
| 10 | $ 3.92 | |||
| 25 | $ 3.70 | |||
| 100 | $ 3.21 | |||
| 250 | $ 3.05 | |||
| 500 | $ 2.73 | |||
| 1000 | $ 2.30 | |||
| 3000 | $ 2.19 | |||
Description
General part information
JPAD100 TO-92 2L ROHS
Diode 35 V 10mA Through Hole TO-92
