CP-01118010
ActiveCvilux USA
CONN RCPT HSG 18POS 4.20MM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsCP Series Flyer
CP-01118010
ActiveCvilux USA
CONN RCPT HSG 18POS 4.20MM
Deep-Dive with AI
DocumentsCP Series Flyer
Technical Specifications
Parameters and characteristics for this part
| Specification | CP-01118010 |
|---|---|
| Color | Natural |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Latch Lock |
| Insulation Material | Polyamide (PA66), Nylon 6/6 |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 18 |
| Number of Rows | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -25 °C |
| Pitch [x] | 4.2 mm |
| Pitch [x] | 0.165 in |
| Row Spacing | 4.2 mm |
| Row Spacing | 0.165 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 0.28 | |
| 10 | $ 0.24 | |||
| 25 | $ 0.21 | |||
| 50 | $ 0.20 | |||
| 100 | $ 0.18 | |||
| 250 | $ 0.16 | |||
| 500 | $ 0.15 | |||
| 1000 | $ 0.13 | |||
| 2500 | $ 0.11 | |||
Description
General part information
CP-01118010
18 Rectangular Connectors - Housings Receptacle Natural 0.165" (4.20mm)
