NACZ221M35V8X10.5TR13F
ActiveNIC Components Corp
CAP ALUM 220UF 20% 35V SMD
Deep-Dive with AI
Search across all available documentation for this part.
NACZ221M35V8X10.5TR13F
ActiveNIC Components Corp
CAP ALUM 220UF 20% 35V SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | NACZ221M35V8X10.5TR13F |
|---|---|
| Applications | General Purpose |
| Capacitance | 220 µF |
| Height - Seated (Max) [Max] | 0.413 in |
| Height - Seated (Max) [Max] | 10.5 mm |
| Impedance | 170 mOhms |
| Lifetime @ Temp. | 2000 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Radial, Can - SMD |
| Polarization | Polar |
| Ripple Current @ High Frequency | 450 mA |
| Ripple Current @ Low Frequency | 270 mA |
| Size / Dimension [diameter] | 0.315 " |
| Size / Dimension [diameter] | 8 mm |
| Surface Mount Land Size [x] | 0.327 " |
| Surface Mount Land Size [x] | 8.3 mm |
| Surface Mount Land Size [y] | 8.3 mm |
| Surface Mount Land Size [y] | 0.327 in |
| Tolerance | 20 % |
| Voltage - Rated | 35 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.70 | |
| 10 | $ 0.47 | |||
| 50 | $ 0.37 | |||
| 100 | $ 0.31 | |||
| Digi-Reel® | 1 | $ 0.70 | ||
| 10 | $ 0.47 | |||
| 50 | $ 0.37 | |||
| 100 | $ 0.31 | |||
| Tape & Reel (TR) | 300 | $ 0.25 | ||
| 600 | $ 0.23 | |||
| 900 | $ 0.22 | |||
| 1500 | $ 0.21 | |||
| 2100 | $ 0.20 | |||
| 3000 | $ 0.19 | |||
| 7500 | $ 0.18 | |||
| 15000 | $ 0.17 | |||
| 30000 | $ 0.16 | |||
Description
General part information
NACZ221M35V8X10.5TR13F
220 µF 35 V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 105°C
