AB-D67100-V24-Q
ActiveAmerican Bright Optoelectronics Corporation
90-305VAC INPUT, 24VDC OUTPUT, 1
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AB-D67100-V24-Q |
|---|---|
| Approval Agency | cULus, TUV, cURus, CE, UKCA |
| Current - Output (Max) [Max] | 4.17 A |
| Dimming | Non-Dimmable |
| Efficiency | 92.5 % |
| Features | OTP, SCP, OVP, OCP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 100 W |
| Ratings | IP67 |
| Size / Dimension [x] | 172.6 mm |
| Size / Dimension [x] | 6.8 " |
| Size / Dimension [y] | 62.5 mm |
| Size / Dimension [y] | 2.46 " |
| Size / Dimension [z] | 1.5 " |
| Size / Dimension [z] | 38 mm |
| Standard Number | UL 8750 |
| Termination Style | Wire Leads |
| Topology | AC DC Converter |
| Type | Constant Current, Voltage |
| Voltage - Input (Max) [Max] | 305 VAC |
| Voltage - Input (Min) [Min] | 90 VAC |
| Voltage - Isolation | 3.2 kV |
| Voltage - Output | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 35.96 | |
| 5 | $ 32.86 | |||
| 10 | $ 31.61 | |||
| 25 | $ 30.02 | |||
| 50 | $ 29.94 | |||
Description
General part information
AB-D67100-V24-Q
4.17A 24V Constant Current, Voltage LED Driver AC DC Converter Topology 1 Output
